steel roofing tile machine
Trapezoidal roofing sheet corrugated Steel Roofing Sheet Making Machine
Pioneers in the industry, we offer gi and ppgi coated roofing sheet, polycarbonate corrugated roofing sheet, color coated roofing sheets, aluminum roofing sheets, tile roof sheets, and tile profiles
#TrapezoidalRoofing
Quantity:







PROFILES





Technical Parameters
Roller stations
18 rows (or according to client requirement)
Shaft Diameter
70mm（or as client requirement)
Middle Plate
16mm with Hanging plate Material
Hydraulic drive (Station)
5.5kw
Press and Cutting System
Guide Pillar system;
Cutting blade material: Cr12, heat treatment HRC58-60
Cutt-off Type
Hydraulic guide Pillar Cutting
Length Tolerance
+/- 2mm
PLC
Delta Inverter, DELTA PLC
Raw Material Thickness
0.16~0.5mm, G300~G550
Productivity
20-25m/min
Voltage
380v 50hz 3p
Raw Material Width
1219mm
Material
Colored steel sheet, Galvanized steel sheet, aluminium steel sheet
Chain
1.25 inch
Steel structure
350# H steel
