Standing Seam Roof System Production Line
Putai Technology Co., Ltd is a Cold Roll Forming Machine Manufacturer
with the goal of manufacturing high-quality forming machines at reasonable prices that go beyond the basic expectations of the customer.
The outstanding technology and quality have propelled the company to become a leader in the field.
A major aspect of our success is our people, Our dynamic, innovative, and motivated personnel will provide the customer with high-quality service, technical information, and assistance.
with the goal of manufacturing high-quality forming machines at reasonable prices that go beyond the basic expectations of the customer.
The outstanding technology and quality have propelled the company to become a leader in the field.
A major aspect of our success is our people, Our dynamic, innovative, and motivated personnel will provide the customer with high-quality service, technical information, and assistance.
#Roof
Quantity:
COLD ROLL FORMINT MACHINE
Standing Seam Roof System Production Line
mquina laminadora para techos
mquina formadora de lminas de techos
roof framing machinery
standing seam type steel panel forming machine
roofing sheet roll forming machine
| 1 | machine structure | cast iron roller fixer |
| 2 | Main power | 5KW siemens motor |
| 3 | Forming stations | 12 stands |
| 4 | Way of drive | high-quality gear drive |
| 5 | Diameter of shaft | 70mm |
| 6 | Max rolling speed | 20-25m/min |
| 7 | Thickness | 0.3-0.5mm galvanized steel or prepainted sheet |
| 8 | Material width | according to drawing |
| 9 | Material of roller | Cr12 |
| 10 | Material of blade mold | Cr12, quenched 58-62 |
| 11 | Way of cutting | hydraulic mold cutting |
| 12 | Length cutting tolerance | +/-1.0mm |
| 13 | Hydraulic pressure | 16Mpa |
| 14 | Hydraulic power | 4kw |
| 15 | Computer Control system | PLC control Delta |
| 16 | Encoder measure | Omron |
| 17 | Electrical requirement | 380V,50Hz,3Ph |
Roofing sheet roll forming machine
